Stainless Steel Push Rod

NIDEC-SHIMPO’s Stainless Steel Push Rods are simple, yet specialized force gauge attachment for testing compression forces on small components or over a specific area of an item under test.

  • Two sizes of 0.2” (5 mm) or 0.4” (10 mm) diameter rods are available, each able to withstand up to 225 lb (102 kg) of compressive forces.
  • Each compressive rod has a M6 female connection, enabling connection with any M6 compatible device.

Grips and attachments sold individually (not in pairs).

Model FG-M6COMP5U FG-M6COMP10U
Max Width 0.2” (5 mm) 0.3” (10 mm)
Max Capacity 225 lb (102 kg) 225 lb (102 kg)

*Grips ending in U = Upper


Download FG-M6COMP5U Dimensions
Download FG-M6COMP10U Dimensions
FG-M6COMP5U 5 mm Diameter Stainless Steel Push Rod, M6 Thread, 225lb (100 kg) Capacity
FG-M6COMP10U 10 mm Diameter Stainless Steel Push Rod, M6 Thread, 225lb (100 kg) Capacity

For use with NIDEC-SHIMPO and M6 compatible force gauges.
